Bullet Loom
Designed and Manufactured With Simple and Convenient Mechanism
-
Weaving Capacity
Up to 250 Gms/sq.meter -
Delivery
within a week to 10 days -
Benefits
Hassle free functionality
Optimum perfromance
Long Service Life
High production of quality fabric with same parameter
Yarn Specifications in Detail:
Driving mechanism of Bullet loom is designed to achieve maximum efficiency by smooth and economical transmission and production by high speed running. The loom is capable of running up to 180 RPM (depending on reed space and fabric quality) without affecting on weaving and machine parts.
Electronic Panel Control:
- Bullet Shuttle loom machine works on computerized control system.
- Push button Panel with Start, Stop, Reveres Inching, Forward Inching, One Pick functions
It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.Lorem Ipsum as their default model text, and a search for ‘lorem ipsum’ will uncover many web sites still in their infancy. Various versions have evolved over the years, sometimes by accident, sometimes on purpose (injected humour and the like).
-
1.BULLET LOOMS is free from clutch break system:
At Paramount, we use computerized braking system. Hence, no electromagnetic brake is required in the motor. Consequently no maintenance of clutch is also needed. -
2.Looms RPM meter
Through the Looms RMP Meter on the Bullet Loom machine, weaver can see loom’s speed on display. -
3.Fabrics production counter
Weaver can check current meter production through a display on Bullet loom. -
4.Cut length setting
weaver can get exact fabrics length as per his requirement, such as 100 meter or 120 meters of as desired cut length rolling.
-
5.Fabric Pick on Display
You can get the data of ‘which pick fabric is weaving?’ through a display on this shuttle loom machine. -
6.Looms start position
You can start or stop looms on 180 degree. -
7.Shift wise production
You can get 7 days back up of 2 or 3 shift wise production data on shuttle loom.
Warp Stop Motion:
- Digital warp stop motion with IR sensor will stop the machine immediately after breaking yarn in warp
- Electronic Drop pin warp stop motion
- Beam tension let-off sensor
Accident Prevention System:
- BULLET LOOMS is well designed to prevent the accidents.
- BULLET LOOM comes with shuttle fly prevention flexible guards to protect the operator from shuttle fly accidents.
Advance Positive Shading Motion:
- BULLET Shuttle Loom is loaded with mild steel material to ensure high performance bearing system shedding. So that the weaver can get excellent feel fall in fabrics and shading change perfectly in motion.
Advance Timing System:
- BULLET LOOM’s timing system has fully laser cut parts and superior performance bearing system. That’s how its 2×1 drop box system works very smoothly without any jerk, so the machine can hassle-free run at high speed.
Extra Support for High Speed:
-
Six Step Rocking Shaft Support:
This system will fully support to slay in high speed running looms and rocking shaft, so that the rocking bearing maintenance will be ‘0’
Financial & technical benefit of Bullet looms for Weavers:
-
Low Power Consumption
Appropriate usage of ball bearings make the movement of machine’s parts easy, which helps in reducing the power consumption. One person can handle 12 to 16 Looms machines depending on preparatory yarn qualities and operator. This can result in good amount of saving in recurring expenses. -
Low maintenance
Since most of the spare parts of Bullet shuttle loom is made from S.G. Cast Iron and Mild Steel, the chances of spares breakages are nil. All these parts are made using the advanced technology automatic CNC machine, VMC, Machine and laser Cut Machine. -
Higher Production:
Designed to deliver superior performance, BULLET LOOM is observed to have low maintenance and minimal down time. Thus weaving through this shuttle loom weaving machine has proved to be cost-effective in improving production speed. -
High Speed Weaving
You can increase the RPM of BULLET LOOM as per your requirement to gain optimum productivity. -
Heavy Reed Pick:
You can weave heavy reed pick on BULLET LOOM machines as compared to other Shuttle loom machines. -
Fully Ball Bearing base looms:
BULLET LOOM is fully loaded with spherical roller and ball bearing base, which helps in getting higher loom-RPM; thereby increased productivity and better fabric weaving. It can weave higher denier and higher picks also.
Bullet high speed semi automatic shuttle loom is
- Manufactured by our highly qualified professionals, using the finest grade components and high-end technology.
- Designed using detailed mechanism that conforms to the industry quality norms.
- Sturdy in construction and offer high machining accuracy that reduces their maintenance costs.
All these practices have allowed us to gain a huge client base across the Indian Subcontinent. Through our PAN India network, our clients can avail Bullet high speed semi-automatic shuttle loom machines within a week to 10 days.With an impressive growth record in industry, we have established ourselves as the most promising power loom manufacturer in India.
